Description
Details:
Now featuring ArmorGlide Technology that is low-friction and rust-resistant, the Powermatic PJ1696T, 16-Inch Jointer offers big capacity and performance in a machine that is loaded with features. A large, center-mounted fence assembly adjusts easily on a rack and pinion system with ram lock. Preset stops on the fence body allow for fast angle set up at 45 degrees in and out, and a positive stop for perfect 90-degree angles. The parallelogram design keeps the table in close proximity to the cutterhead for improved finish, and allows for a fast depth of cut adjustment.
This design also ensures the tables remain perfectly parallel even after years of tough duty. The specially-designed solid steel helical cutterhead consists of six rows of precision-ground staggered inserts. This system makes fast work of knife changing and never needs adjustment. The heavy-duty 7-1/2-HP motor delivers all the power you need for even the biggest jobs.Features:
- ArmorGlide Technology gives you a low-friction, industrial-grade coating on the work surface that is rust resistant, requires less maintenance, and gives you more control.
- Cast iron fence bevel controls with positive stops at 45 degrees and 90 degrees
- Full size rabbeting table supports large workpieces for rabbets up to 3/4" deep
- Helical cutterhead with 58 two-sided knife inserts reduces noise, eliminates adjustments, and speeds knife change
- Large 16" x 96" precision ground cast iron table surface for maximum support and fine finish
- Parallelogram construction maintains close table-to-cutterhead proximity and ensures table parallelism
- Rack and pinion adjustable cast iron fence system for smoother fence positioning and sturdy work support
- NOTE: The recommended max cutting depth for non-rabbeting cuts is 1/8”. The max cutting depth for rabbeting cuts is 1/2" as the manual has always stated.
Specifications:
Stock Number PM1-1791283T-4 Model Number PJ1696T Warranty 5 Year Type of Cutterhead Helical Head Cutterhead Diameter (In.) 4 Maximum Cutting Depth (In.) 1/8" Cuts Per Minute 20,800 Cutterhead Speed (RPM) 5200.0000 Cutting Capacity (W x D) (In.) 16 x 3/4 Dust Collection Minimum CFM Required (CFM) 800 Dust Port Outside Diameter (In.) 6 Infeed Table Length (In.) 47-1/2 Number of Knives 58 Motor Power (HP) 7-1/2 Motor Voltage (V.) 460 Prewired Voltage (V.) 460 Motor Phase 3 Max.Rabbeting Capacity (In.) 3/4" Table Height from Floor (In.) 37-1/2 Gross Weight 1400.0 Net weight 1280.0 Prop 65 Cancer and Reproductive Harm -
