Irwin M22 x 1.50mm HCS Hexagon Metric Die (8565)

The Irwin M22 x 1.50mm HCS Hexagon Metric Die (8565) is a specialized threading tool designed for a variety of applications where metric threads are specified. It is particularly well-suited for use in automotive repair and machinery, where the M22 x 1.50mm thread size is a common requirement. Made from high-carbon steel, this die is engineered to create new threads on rods or bolts and to repair existing, damaged threads. The hexagon shape is a key feature, as it allows the die to be driven by a standard wrench or socket, making it easy to use in tight spaces or on-the-go.

KEY FEATURES AND BENEFITS:

• Precision Threading: Engineered to cut or repair threads to the exact M22 x 1.50mm metric specification, ensuring a perfect fit for corresponding bolts and nuts.
• High-Carbon Steel Construction: Made from high-quality HCS (High-Carbon Steel), providing good hardness and wear resistance for a long service life and consistent performance.
• Hexagon Shape: The unique hexagon design allows the die to be turned with a standard wrench, socket, or adjustable spanner, offering great versatility and ease of use without needing a dedicated die stock.
• Versatile Application: Specifically suited for automotive repair and machinery, this die can be used to create new threads on metal rods or bolts, as well as to clean up and restore old or damaged threads.
• Efficient Thread Repair: A simple and effective solution for correcting stripped or cross-threaded fasteners, saving time and the cost of replacement parts.

SPECIFICATIONS:

• Thread Type: Metric
• Thread Size: M22 x 1.50mm
• Material: HCS (High-Carbon Steel)
• Product ID: 8565

HOW TO USE:

1. Preparation: Secure the workpiece (the rod or bolt you intend to thread) in a vise. Make sure the end of the workpiece is chamfered slightly to help the die start straight. Select an appropriate wrench or socket that fits the hexagon shape of the die.
2. Starting the Thread: Place the die over the end of the workpiece. Apply downward pressure and turn the die clockwise (for right-hand threads) while keeping it as straight as possible. The initial turn is crucial for ensuring a straight thread.
3. Cutting the Thread: Continue to turn the die clockwise, applying steady pressure. After every half-turn to one full turn, reverse the die slightly (turn it counter-clockwise) to break and clear the chips from the cutting teeth. This prevents clogging and ensures a cleaner thread.
4. Finishing: Once the die has traveled the desired length of the thread, turn it counter-clockwise to remove it from the workpiece. Use a brush or compressed air to remove any remaining metal chips.

BENEFITS OF USING IRWIN M22 X 1.50MM HCS HEXAGON METRIC DIE (8565):

• Saves time and money by allowing for the repair of damaged threads instead of replacing entire components.
• Provides a simple, portable threading solution that doesn't require bulky or specialized equipment.
• Ensures that threads are cut to the correct metric specification, which is critical for safety and proper function in mechanical assemblies.
• The high-carbon steel construction offers a reliable tool that maintains its cutting edge through repeated use.
• Its compact hexagon design makes it easy to store in a toolbox and readily accessible for a variety of tasks.

FEATURES:

• Metric Threading: Designed for M22 x 1.50mm thread specification.
• Thread Repair: Ideal for cleaning and restoring damaged external threads.
• New Thread Creation: Capable of cutting new threads on various materials.
• Tool Versatility: Can be used in conjunction with common hand tools.
